 REVERSE

Description

This command reverses a region in image buffer.

Syntax

REVERSE x_start,y_start,x_width,y_height

Parameter

Description

x_start

The x-coordinate of the starting point (in dots)

y_start

The y-coordinate of the starting point (in dots)

x_width

X-axis region width (in dots)

y_height

Y-axis region height (in dots)

Note:

 200 DPI: 1 mm = 8 dots

300 DPI: 1 mm = 12 dots

 Recommended max. height of reversed black area is 12mm at 4” width. Height of reversed

area that is larger than 12 mm may damage the power supply and affect the print quality.

 Max. print ratio is different for each printer model. Desktop and industrial printer print ratio

is limited to 20% and 30% respectively.

Example

Sample code

SIZE 4,2.5

GAP 0,0

DIRECTION 1

CLS

TEXT 100,100,"3",0,1,1,"REVERSE"

REVERSE 90,90,128,40

PRINT 1,1

Result
