 BLINE
Description
This command sets the height of the black line and the user-defined extra label feeding length each
form feed takes.
Syntax
BLINE m,n
English system (inch)
BLINE m mm,n mm
Metric system (mm)
BLINE m dot,n dot
Dot measurement
This command has been supported since V6.27 EZ and later firmware.
Parameter
Description
m
The height of black line either in inch or mm
0 ≤ m ≤ 1 (inch), 0 ≤ m ≤ 25.4 (mm)
n
The extra label feeding length
0 ≤ n ≤ label length
0,0
Continuous label
Note:
 For metric system, there must be a space between parameter and mm.
 When the sensor type is changed from “GAP” to “Black Mark”, please send the “BLINE”
command to the printer first.
 200 DPI : 1 mm = 8 dots
300 DPI : 1mm = 12 dots
Example
Sample Code
 English system (inch):
BLINE 0.20,0.50
 Metric system (mm):
BLINE 5.08 mm,12.7 mm
See Also
SIZE, GAP
