TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 144 Copyright 2013 All Rights Reserved.
 INPUT
Description
This command receives data through specific port. This command is used with portable keyboard
KP-200.
Syntax
INPUT ["Prompt string", number of digits], variables
The comma also can be replaced by semicolon, such as:
INPUT ["Prompt string"; number of digits]; variables
Parameter
Description
Prompt string
The prompt string is shown on keyboard LCD screen. The maximum length
of prompt string is 20 characters
Number of digits
Maximum number of characters is 255
Variables
The variable to receive input data
Example
Sample code
DOWNLOAD "TEXT.BAS"
SIZE 4,3
GAP 0,0
DIRECTION 1
:START
INPUT "CODE 39 :",C39$
INPUT "EAN 13:",12,E13$
CLS
TEXT 20,50,"3",0,1,1,"INPUT and KP-200 Test"
BARCODE 20,100,"39",48,1,0,2,5,C39$
BARCODE 20,200,"EAN13",48,1,0,4,4,E13$
PRINT 1
GOTO START
EOP
TEXT
123456
123456789012
Result
See Also
DOWNLOAD, EOP, END, GOTO

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
