TSC AUTO ID Technology Co., Ltd. 177 Copyright 2013 All Rights Reserved.
SET BACK
Description
This setting is used after SET CUTTER function. This function prevents label backfeeding after a cut.
Syntax
SET BACK OFF/ON
Parameter
Description
OFF
Disable back function.
ON
Enable back function.
Model
Support
TTP-243 series
TTP-243 Plus series
V
TTP-244ME series
TTP-244ME Plus series
V
TTP-244 series
V
TTP-244CE series
TTP-245 series
V
TTP-245C series
V
TDP-245 series
V
TTP-246M series
V
TTP-248M series
TTP-2410M series
V
TDP-643 Plus
TDP-643R Plus
V
TTP-342 series
TTP-342 Plus series
V
TTP-342M series
TTP-342M Plus series
V
TTP-343 series
V
TTP-343C series
V
TTP-344M series
V
TTP-346M series
V
TTP-384M series
V
TTP-644M series
V
M23 series
Example
Sample code
REM **SET BACK FUNCTION OFF EXAMPLE PROGRAM**
SIZE 3,1
GAP 0,0
DENSITY 8
SPEED 6
DIRECTION 1
REFERENCE 0,0
SET CUTTER 1
SET BACK OFF
CLS
TEXT 50,50,"3",0,1,1,"SET BACK OFF"
PRINT 3
CLS
