TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 46 Copyright 2013 All Rights Reserved.
 ELLIPSE
Description
This command draws an ellipse on the label.
Syntax
ELLIPSE x,y,width,height,thickness
Parameter
Description
x
Specify x-coordinate of upper left corner (in dots)
y
Specify y-coordinate of upper left corner (in dots)
width
Specify the width of the ellipse (in dots)
height
Specify the height of the ellipse (in dots)
thickness
Thickness of the ellipse (in dots)
Note:
This command has been supported since V6.91 EZ and later firmware.
Example
Sample code
SIZE 4,3
GAP 0,0
DIRECTION 1
CLS
BOX 10,10,410,110,1
ELLIPSE 10,10,400,100,2
BOX 10,120,110,520,1
ELLIPSE 10,120,100,400,5
PRINT 1
Result

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
