TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 192 Copyright 2013 All Rights Reserved.
 SET RIBBONEND
Description
This setting is used to enable/disable ribbon-end sensor detection.
Syntax
SET RIBBONEND ON/OFF
Parameter
Description
ON
Enable ribbon-end sensor.
OFF
Disable ribbon-end sensor.
Note:
This command has been supported since V6.91 EZ and later firmware.
Example
SET RIBBONEND ON
SET RIBBONEND OFF

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
