TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 228 Copyright 2013 All Rights Reserved.
External Wi-Fi Module Setting Commands
 WLAN OFF
Description
This command is used to disable Wi-Fi module. Restart the printer is necessary.
Syntax
WLAN OFF
Note:
We can use command SELFTEST WLAN to check the status of WLAN. The SSID is empty.
Example
Sample code
WLAN OFF
SELFTEST WLAN
Result
See Also
WLAN SSID

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
