TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 204 Copyright 2013 All Rights Reserved.
 SET AUTORUN
Description
This command redefines the BAS file which can be run automatically while switching on the printer.
Default is AUTO.BAS.
Syntax
SET AUTORUN "filename"
Parameter
Description
filename
The file will be defined to AUTO-RUN file. Default is AUTO.BAS.
Note:
 This command has been supported since V6.86 EZ and later firmware.
Example
Sample Code
REM *****Step1: Send the following command to redefine the auto-run file from "AUTO.BAS" to
"TEST.BAS"
SET AUTORUN "TEST.BAS"
REM *****Step2: Send the following commands to download "TEST.BAS" file into printer.
DOWNLOAD F,"TEST.BAS"
SIZE 4,1
GAP 0,0
DIRECTION 1
CLS
BLOCK 10,10,600,200,"3",0,1,1,12,"\["]TEST.BAS\["] is running automatically while turning on the
printer."
PRINT 1
EOP
REM *****Step3: Turn off and on the printer to run "TEST.BAS" automatically.
Result

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
