TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. VI Copyright 2013 All Rights Reserved.
Document Conventions
This manual uses the following typographic conventions.
Convention
Description
[expression list]
Items inside square brackets are optional, expression maximum length 2*1024
bytes.
<ESC>
ASCII 27, control code of status polling command returns/runs the printer
status immediately.
~
ASCII 126, control code of status polling command returns the printer status
only when the printer is ready.
Space
ASCII 32, characters will be ignored in the command line.
"
ASCII 34, beginning and ending of expression.
CR, LF
ASCII 13, ASCII 10, denotes end of command line.
NULL
ASCII 0, supported in the expression.
Note:
203 DPI: 1 mm = 8 dots
The font in bold and italic type is used for note.

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
