TSC TTP-244 Plus Programming Manual

TSC AUTO ID Technology Co., Ltd. 2 Copyright 2013 All Rights Reserved.
 GAP
Description
Defines the gap distance between two labels.
Syntax
GAP m,n
English system (inch)
GAP m mm,n mm
Metric system (mm)
GAP m dot,n dot
Dot measurement
This command has been supported since V6.27 EZ and later firmware.
Parameter
Description
M
The gap distance between two labels
0 ≤ m ≤1 (inch), 0 ≤ m ≤ 25.4 (mm)
N
The offset distance of the gap
n ≤ label length (inch or mm)
0, 0
Continuous label
Note :
 200 DPI : 1 mm = 8 dots
300 DPI : 1mm = 12 dots
 For metric and dot systems, there must be a space between parameter and mm.
 When the sensor type is changed from “Black Mark” to “GAP”, please send the “GAP”
command to the printer first.

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
