Vacon NX series Applications Manual

Table 36: Input signals, G2.2
Index Parameter Min Max Unit Default Cust ID Description
P2.2.39 AI3 signal range 0 1 1 143
0 = Signal range 0
—10 V
1 = Signal range 2
—10 V
P2.2.40 AI3 inversion 0 1 0 151
0 = Not inverted
1 = Inverted
P2.2.41 AI3 filter time 0.00 10.00 s 0.10 142 0 = No filtering
P2.2.42
***
AI4 signal selec-
tion
0.1 E.10 0.1 152
TTF programming
method used. See
Chapter 8.9 "Ter-
minal to function"
(TTF) programming
principle.
P2.2.43 AI4 signal range 0 1 1 154
0 = Signal range 0
—10 V
1 = Signal range 2
—10 V
P2.2.44 AI4 inversion 0 1 0 162
0 = Not inverted
1 = Inverted
P2.2.45 AI4 filter time 0.00 10.00 s 0.10 153 0 = No filtering
P2.2.46
Actual value spe-
cial display mini-
mum
0 30000 0 1033
P2.2.47
Actual value spe-
cial display maxi-
mum
0 30000 100 1034
P2.2.48
Actual value spe-
cial display deci-
mals
0 4 1 1035
P2.2.49
Actual value spe-
cial display unit
0 29 4 1036
See ID1036 in
Chapter 8 Parame-
ter descriptions.
CP = control place
cc = contact
oc = opening contact
* = Remember to place jumpers of block X2 accordingly. See the product's User Manual.
PID CONTROL APPLICATION VACON · 109
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
5

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
