Table 53: Appliction Status word content
Application
Standard Loc/Rem Multi-Step PID MP PFC
Status Word
b0
b1 Ready Ready Ready Ready Ready Ready
b2 Run Run Run Run Run Run
b3 Fault Fault Fault Fault Fault Fault
b4
b5
No EMStop
(NXP)
b6 Run Enable Run Enable Run Enable Run Enable Run Enable Run Enable
b7 Warning Warning Warning Warning Warning Warning
b8
b9
b10
b11 DC Brake DC Brake DC Brake DC Brake DC Brake DC Brake
b12 Run request Run request Run request Run request Run request Run request
b13 Limit control Limit control Limit control Limit control Limit control Limit control
b14 Brake control Aux 1
b15
Place B is
active
PID active Aux 2
MULTI-PURPOSE CONTROL APPLICATION VACON · 141
