Page #152 background imageLoading...
Page #152 background image
Table 60: Free analogue input, signal selection (Keypad: Menu M2 -> G2.2.6)
Index Parameter Min Max Unit Default Cust ID Description
P2.2.6.1
Scaling of current
limit
0 5 0 399
0 = Not used
1= AI1
2 = AI2
3 = AI3
4 = AI4
5 = FB Limit Scal-
ing See group G2.9
P2.2.6.2
Scaling of DC-
braking current
0 5 0 400
As parameter
P2.2.6.1 Scaling
from 0 to ID507.
P2.2.6.3
Scaling of acc./
dec. times
0 5 0 401
As parameter
P2.2.6.1 Scales
active ramp from
100 % to 10 %.
P2.2.6.4
Scaling of torque
supervision limit
0 5 0 402
As parameter
P2.2.6.1 Scaling
from 0 to ID348.
P2.2.6.5
Scaling of torque
limit
0 5 0 485
As parameter
P2.2.6.1 Scaling
from 0 to (ID609
(NXS) or ID1287
(NXP)).
NXP drives only
P2.2.6.6
Scaling of genera-
tor torque limit
0 5 0 1087
As parameter
P2.2.6.1 Scaling
from 0 to ID1288.
P2.2.6.7
Scaling of motor-
ing power limit
0 5 0 179
As parameter
P2.2.6.1 Scaling
from 0 to ID1289.
P2.2.6.8
Scaling of genera-
tor power limit
0 5 0 1088
As parameter
P2.2.6.1 Scaling
from 0 to ID1290.
Use TTF programming method for all Digital inputs parameters. See Chapter 8.9 "Terminal
to function" (TTF) programming principle
VACON · 152 MULTI-PURPOSE CONTROL APPLICATION
6
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205
