Table 61: Digital inputs (Control keypad: Menu M2 -> G2.2.4)
Index Parameter Min Default Cust ID Description
P2.2.7.1 * Start signal 1 0.1 A.1 403 See P2.2.1.1.
P2.2.7.2 * Start signal 2 0.1 A.2 404 See P2.2.1.1.
P2.2.7.3 * Run enable 0.1 0.2 407 Motor start enabled (cc)
P2.2.7.4 * Reverse 0.1 0.1 412
Direction forward (oc)
Direction reverse (cc)
P2.2.7.5 * Preset speed 1 0.1 0.1 419 See preset speeds in Basic
Parameters (G2.1).
P2.2.7.6 * Preset speed 2 0.1 0.1 420
P2.2.7.7 * Preset speed 3 0.1 0.1 421
P2.2.7.8 *
Motor potentiometer refer-
ence DOWN
0.1 0.1 417
Mot.pot. reference decrea-
ses (cc).
P2.2.7.9 *
Motor potentiometer refer-
ence UP
0.1 0.1 418
Mot.pot. reference increases
(cc).
P2.2.7.10 * Fault reset 0.1 A.3 414
Resets all active faults when
TRUE.
P2.2.7.11 * External fault (close) 0.1 A.5 405 Ext. fault (F51) displayed (cc).
P2.2.7.12 * External fault (open) 0.1 0.2 406
Ext. fault (F51) displayed
(oc).
P2.2.7.13 * Acc/Dec time selection 0.1 A.6 408
Acc/Dec time 1 (oc)
Acc/Dec time 2 (cc)
P2.2.7.14 * Acc/Dec prohibit 0.1 0.1 415
No acceleration or decelera-
tion is possible until the con-
tact is open.
P2.2.7.15 * DC braking 0.1 0.1 416 DC braking active (cc).
P2.2.7.16 * Jogging speed 0.1 A.4 413
Jogging speed selected for
frequency reference (cc).
P2.2.7.17 * AI1/AI2 selection 0.1 0.1 422
cc = AI2 is used as reference,
when ID117 = 14
P2.2.7.18 * Control from I/O terminal 0.1 0.1 409
Force Control to I/O termi-
nal.
P2.2.7.19 * Control from keypad 0.1 0.1 410 Force Control to Keypad.
P2.2.7.20 * Control from fieldbus 0.1 0.1 411 Force Control to Fieldbus.
MULTI-PURPOSE CONTROL APPLICATION VACON · 153
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
