Table 64: Digital ouput signals (Control keypad: Menu M2 -> G2.2.4)
Index Parameter Min Default Cust ID Description
P2.3.3.1 * Ready 0.1 A.1 432 Ready to Run
P2.3.3.2 * Run 0.1 B.1 433 Running
P2.3.3.3 * Fault 0.1 B.2 434 Drive in fault state
P2.3.3.4 * Inverted fault 0.1 0.1 435 Drive not in fault state
P2.3.3.5 * Warning 0.1 0.1 436 Warning active
P2.3.3.6 * External fault 0.1 0.1 437 External fault active
P2.3.3.7 * Reference fault/warning 0.1 0.1 438 4 mA fault or warning active
P2.3.3.8 * Overtemperature warning 0.1 0.1 439 Drive overtemperature active
P2.3.3.9 * Reverse 0.1 0.1 440 Output frequency < 0 Hz
P2.3.3.10 * Unrequested direction 0.1 0.1 441
Actual direction <> reques-
ted direction
P2.3.3.11 * At speed 0.1 0.1 442
Reference = Output fre-
quency
P2.3.3.12 * Jogging speed 0.1 0.1 443
Jogging or preset speed
command active
P2.3.3.13 * I/O control place 0.1 0.1 444 IO control active
P2.3.3.14 * External brake control 0.1 0.1 445 See IDs 445 and 446 in Chap-
ter 8 Parameter descriptions.
P2.3.3.15 *
External brake control,
inverted
0.1 0.1 446
P2.3.3.16 *
Output frequency limit 1
supervision
0.1 0.1 447
See ID315 in Chapter 8
Parameter descriptions.
P2.3.3.17 *
Output frequency limit 2
supervision
0.1 0.1 448
See ID346 in Chapter 8
Parameter descriptions.
P2.3.3.18 * Reference limit supervision 0.1 0.1 449
See ID350 in Chapter 8
Parameter descriptions.
P2.3.3.19 *
Temperature limit supervi-
sion
0.1 0.1 450
Drive temperature supervi-
sion. See ID354 in Chapter 8
Parameter descriptions.
P2.3.3.20 * Torque limit supervision 0.1 0.1 451
See ID348 in Chapter 8
Parameter descriptions.
P2.3.3.21 * Themistor fault or warning 0.1 0.1 452
P2.3.3.22 *
Analogue input supervision
limit
0.1 0.1 463
See ID356 in Chapter 8
Parameter descriptions.
VACON · 158 MULTI-PURPOSE CONTROL APPLICATION
6
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205
