Vacon NX series Applications Manual

Table 78: Protections, G2.7
Index Parameter Min Max Unit Default Cust ID Description
P2.7.24 TBoard1 Numbers 0 5 0 739
0 = Not used
1 = Channel 1
2 = Channel 1 & 2
3 = Channel 1 & 2
& 3
4 = Channel 2 & 3
5 = Channel 3
P2.7.25 TBoard Flt. Resp 0 3 0 740
0 = No response
1 = Warning
2 = Fault, stop acc.
to 2.4.7
3 = Fault, stop by
coasting
P2.7.26
TBoard1
Warn.Lim
-30.0 200.0 ºC 120.0 741
Set here the limit
at which the tem-
perature warning
will be activated.
P2.7.27 TBoard1 Flt.Lim -30.0 200.0 ºC 130.0 742
Set here the limit
at which the tem-
perature fault
(F65) will be acti-
vated.
NXP drives only
P2.7.28 Brake fault action 1 3 1 1316
1 = Warning
2 = Fault, stop acc.
to 2.4.7
3 = Fault, stop by
coasting
P2.7.29 Brake fault delay 0.00 320.00 s 0.20 1317
P2.7.30 System bus fault 3 3 3 1082
0 = No response
1 = Warning
2 = Fault, stop acc.
to 2.4.7
3 = Fault, stop by
coasting
P2.7.31
System bus fault
delay
0.00 10.00 s 3.00 1352
P2.7.32 Cooling fault delay 0.00 7.00 s 2.00 751
MULTI-PURPOSE CONTROL APPLICATION VACON · 183
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
