Vacon NX series Applications Manual

Table 78: Protections, G2.7
Index Parameter Min Max Unit Default Cust ID Description
P2.7.38
TBoard2
Warn.Lim
-30.0 200.0 Cº 120 745
Set here the limit
at which the tem-
perature warning
will be activated.
P2.7.39 TBoard2 Flt.Lim -30.0 200.0 Cº 130 746
Set here the limit
at which the tem-
perature fault
(F65) will be acti-
vate.
MULTI-PURPOSE CONTROL APPLICATION VACON · 185
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
