Table 92: Digital output signals (Control keypad: Menu M2 -> G2.3.1)
Index Parameter Min Default Cust ID Description
P2.3.1.1 Ready 0.1 0.1 432 Ready to run
P2.3.1.2 Run 0.1 0.1 433 Running
P2.3.1.3 Fault 0.1 A.1 434 Drive in Fault state
P2.3.1.4 Inverted fault 0.1 0.1 435 Drive not in Fault state
P2.3.1.5 Warning 0.1 0.1 436 Warning active
P2.3.1.6 External fault 0.1 0.1 437 External fault active
P2.3.1.7
Reference fault/
warning
0.1 0.1 438
4 mA fault active
P2.3.1.8
Overtemperature
warning
0.1 0.1 439
Drive overtemperature active
P2.3.1.9 Reverse 0.1 0.1 440 Output frequency < 0 Hz
P2.3.1.10
Unrequested
direction
0.1 0.1 441
Ref <> Output frequency
P2.3.1.11 At speed 0.1 0.1 442 Ref = Output frequency
P2.3.1.12 Jogging speed 0.1 0.1 443 Jogging or preset speed command active
P2.3.1.13
External control
place
0.1 0.1 444
IO control active
P2.3.1.14
External brake
control
0.1 0.1 445
See ID445 in Chapter 8 Parameter descrip-
tions.
P2.3.1.15
External brake
control, inverted
0.1 0.1 446
P2.3.1.16
Output frequency
limit 1 supervision
0.1 0.1 447
See ID315 in Chapter 8 Parameter descrip-
tions.
P2.3.1.17
Output frequency
limit 2 supervision
0.1 0.1 448
See ID346 in Chapter 8 Parameter descrip-
tions.
P2.3.1.18
Reference limit
supervision
0.1 0.1 449
See ID350 in Chapter 8 Parameter descrip-
tions.
P2.3.1.19
Drive temperature
limit supervision
0.1 0.1 450
Drive temperature supervision. See ID354
in Chapter 8 Parameter descriptions.
P2.3.1.20
Torque limit
supervision
0.1 0.1 451
See ID348 in Chapter 8 Parameter descrip-
tions.
P2.3.1.21
Motor thermal
protection
0.1 0.1 452
Thermistor fault or warning
PUMP AND FAN CONTROL APPLICATION VACON · 215
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
