Vacon NX series - Page 217

Table 93: Limit settings (Control keypad: Menu M2 -> G2.3.2)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.2.1
Output frequency
limit 1 supervision
0 2 0 315
0 = No limit
1 = Low limit
supervision
2 = High limit
supervision
P2.3.2.2
Output frequency
limit 1; Supervised
value
0.00 320.00 Hz 0.00 316
P2.3.2.3
Output frequency
limit 2 supervision
0 2 0 346
0 = No limit
1 = Low limit
supervision
2 = High limit
supervision
P2.3.2.4
Output frequency
limit 2; Supervised
value
0.00 320.00 Hz 0.00 347
P2.3.2.5
Torque limit
supervision
0 2 0 348
0 = Not used
1 = Low limit
supervision
2 = High limit
supervision
P2.3.2.6
Torque limit
supervision value
-300.0 300.0 % 100.0 349
Absolute values
are used for brake
control.
P2.3.2.7
Reference limit
supervision
0 2 0 350
0 = Not used
1 = Low limit
2 = High limit
P2.3.2.8
Reference limit
supervision value
0.0 100.0 % 0.0 351
P2.3.2.9
External brake-off
delay
0.0 100.0 s 0.5 352
From brake-off
limits
P2.3.2.10
External brake-on
delay
0.0 100.0 s 1.5 353
From Run request.
Use time longer
than P2.1.4.
P2.3.2.11
FC temperature
supervision
0 2 0 354
0 = Not used
1 = Low limit
2 = High limit
PUMP AND FAN CONTROL APPLICATION VACON · 217
