Vacon NX series Applications Manual

Table 195: Selections for parameter ID1081
Selection
number
Function Description
0 Analogue input 1 (AI1) See ID377
1 Anlogue input 2 (AI2) See ID388
2 AI1+AI2
3 AI1–AI2
4 AI2–AI1
5 AI1*AI2
6 AI1 joystick
7 AI2 joystick
8 Keypad reference (R3.2)
9 Fieldbus reference
10
Potentiometer reference; con-
trolled with ID418
(TRUE=increase) and ID417
(TRUE=decrease)
11 AI1 or AI2, whichever is lower
12 AI1 or AI2, whichever is greater
13
Max. frequency ID102 (recom-
mended in torque control only)
14 AI1/AI2 selection See ID422
15 Encoder 1 (AI input C.1)
16
Encoder 2 (With OPTA7 Speed
Synchronization, NXP only AI
input C.3)
17 Master Reference
18 Master Ramp Out (default)
1082 SYSTEMBUS COMMUNICATION FAULT RESPONSE 6 (2.7.30)
Defines the action when SystemBus heartbeat is missing.
VACON · 354 PARAMETER DESCRIPTIONS
8
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
