Vacon NX series Applications Manual

Table 25: Basic parameters G2.1
Index Parameter Min Max Unit Default Cust ID Description
P2.1.10 * Motor cos phi 0.30 1.00 0.85 120
Find the value on
the rating plate of
the motor.
P2.1.11 * I/O reference 0 3 1 117
0 = AI1
1 = AI2
2 = Keypad
3 = Fieldbus
P2.1.12 *
Keypad control
reference
0 3 2 121
0 = AI1
1 = AI2
2 = Keypad
3 = Fieldbus
P2.1.13 *
Fieldbus control
reference
0 3 3 122
0 = AI1
1 = AI2
2 = Keypad
3 = Fieldbus
P2.1.14 Jogging speed ref. 0.00 P2.1.2 Hz 0.00 124
P2.1.15 Preset speed 1 0.00 P2.1.2 Hz 5.00 105
Speeds preset by
operator.
P2.1.16 Preset speed 2 0.00 P2.1.2 Hz 10.00 106
Speeds preset by
operator.
P2.1.17 Preset speed 3 0.00 P2.1.2 Hz 12.50 126
Speeds preset by
operator.
P2.1.18 Preset speed 4 0.00 P2.1.2 Hz 15.00 127
Speeds preset by
operator.
P2.1.19 Preset speed 5 0.00 P2.1.2 Hz 17.50 128
Speeds preset by
operator.
P2.1.20 Preset speed 6 0.00 P2.1.2 Hz 20.00 129
Speeds preset by
operator.
P2.1.21 Preset speed 7 0.00 P2.1.2 Hz 22.50 130
Speeds preset by
operator.
P2.1.22 Preset speed 8 0.00 P2.1.2 Hz 25.00 133
Speeds preset by
operator.
P2.1.23 Preset speed 9 0.00 P2.1.2 Hz 27.50 134
Speeds preset by
operator.
P2.1.24 Preset speed 10 0.00 P2.1.2 Hz 30.00 135
Speeds preset by
operator.
MULTI-STEP SPEED CONTROL APPLICATION VACON · 75
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
4

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
