Vertiv™ NetSure™ Control Unit (NCU) User Manual
235
Table 6.1
settingTemperatureCompProbe
Temperature Compensation Probe
None (0)
Maximum Probe Temperature (1)
Average Probe Temperature (2)
Minimum Probe Temperature (99)
System Temp1 (4)
System Temp2 (5)
System Temp3 (6)
IB2-1 Temp1 (7)
IB2-2 Temp2 (8)
EIB1 Temp1 (9)
EIB1 Temp2 (10)
R/W
Alarm Trap Counter
alarmLastTrapNo The sequence number of last submitted alarm trap, also last row in alarmTrapTable. R
Active Alarm Table
alarmIndex The unique sequence number of this alarm trap. R
alarmTime Date and time when event occurred (local time), including timezone if supported by controller. R
alarmStatusChange
The type of alarm change. One of...
(1) activated
(2) deactivated
R
alarmSeverity
The severity of the alarm. One of...
(3) warning - OA, lowest level of alarm severity
(4) minor - A3
(5) major - MA
(6) critical - CA, highest level of alarm severity
R
alarmDescription Free-text description of alarm. R
alarmType Alarm type, i.e. an integer specifying the type of alarm. R
Events/ Tra p s
alarmTrap
An alarm trap is sent when an alarm occurs (activated) or returns to normal state (deactivated).
Alarm traps are logged in alarmTrapTable. Variables in this trap:
* alarmIndex
The unique sequence number of this alarm trap.
* alarmTime
Date and time when event occurred (local time), including timezone if supported by controller.
* alarmStatusChange
(1) activated or (2) deactivated.
* alarmSeverity
Integer describing the severity of the alarm.
* alarmDescription
Free-text description of alarm.
* alarmType
Integer indicating type of alarm.
--
alarmActiveTrap
An alarm trap is sent when an alarm occurs (activated). Variables in this trap:
* alarmTime
Date and time when event occurred (local time), including timezone if supported by controller.
* alarmSeverity
Integer describing the severity of the alarm.
* alarmDescription
Free-text description of alarm.
* alarmType
Integer indicating type of alarm.
--
