9-6 Technical Drawings Rev AB
Videojet 8520 Operator Manual
Adapter Plate for Sensor
Spacer Plate for Sensor, for use with a Locating Wheel
Figure 9-7: Adapter Plate Dimensions
2
0
3,50
7
19
34
Ø3,30
R5
10
Figure 9-8: Spacer Plate Dimensions
