9-8 Technical Specifications Rev AB
Videojet 8520 Operator Manual
Parallelogram
Technical Specifications
Table 9-1 lists the technical specifications of the printhead.
Technical
Specification
Length
(L) in
mm
Width
(W) in
mm
Height
(H) in
mm
Weight in grams
Printhead, blue 75 205 30 298
the view shows:
jet plate, bottom;
printhead from
the right
Table 9-1: Technical Specifications
Figure 9-10: Parallelogram Dimensions
