Rev AB Installation of the Mounting System (Optional) 3-25
Videojet 8520 Operator Manual
Installation of the Mounting System (Optional)
The mounting system for single-head mounting allows fast and simple
printhead mounting.
The adjusting unit for multi-head mounting (all printhead versions) is as
shown in Figure 3-38. This enables printheads to be finely adjusted for
perfect print images.
Figure 3-37: Single-head Mounting of a Blue Printhead
Figure 3-38: Adjusting Unit
