SHB 803 en – Edition 2.4 * 803s110.fm 1-5
Operation
1.4 Labels
Serial number
The serial number is located on the type label.
The serial number is also stamped on the machine chassis.
Refer to the Operator’s Manual of the machine for more information.
Diesel engine type label
The type label (arrow) is located on the cylinder-head cover (engine).
Hydraulic pump type label
The type label (arrow) is located on the hydraulic pump housing.
Main valve block type label
The type label (arrow) is located on the lower side of the main valve block.
Traveling drive type label
The type label (arrow) is located on the traveling drive.
Fig. 1: Type label (symbolic representation)
Fig. 2: Diesel engine type label
Fig. 3: Hydraulic pump type label
Fig. 4: Main valve block type label
Fig. 5: Traveling drive type label
