1.5 Machine overview (up to serial no. AI00966)
Fig. 7: Machine outside views
1 Boom light
2 Boom
3Stick
4Track
5 Travel gear
6 Stabilizer blade
7 Handhold
8 Lifting eye for loading/tying down the machine
9 Engine cover
10 Storage bin for Operator’s Manual
11 Lock lever
12 Track tensioner
