SHB 803 en – Edition 2.4 * 803s510.fm 5-9
Hydraulic system
Pressure limiting valves
2
1
5
3
7
6
4
Pos. Designation
1 Primary pressure limiting valve P1
2 Secondary pressure limiting valve, swivel, right
3 Anticavitation valve
4 Primary pressure limiting valve P2
5 Secondary pressure limiting valve, swivel, left
6 Secondary pressure limiting valve, stick
7 Anticavitation valve
