3-44 SHB 803 en – Edition 2.4 * 803s314.fm
Maintenance
Lubrication strip
Apply grease to the lubrication strip as follows:
☞Lubrication point A for live ring ball bearing
➥Grease: BP Energrease MP-MG2
☞Lubrication point B for the swiveling cylinder
Apply grease to lubrication points A and B once a day.
Fig. 43: Lubrication strip on the chassis
B
A
