SHB 803 en – Edition 2.4 * 803s210.fm 2-5
Technical data
Auxiliary hydraulics oil flow
Output indications for auxiliary hydraulics with unpressurized return line
2.4 Travel gear and swivel unit
2.5 Stabilizer blade
Screwable hose burst valve
Pressure (bar/psi) P1 + P2 (l/min / gal/min)
12.5/181.3 22/5.8
37.8/548.2 20.8/5.5
50/725.2 20.4/5.4
79/1145.8 19.7/5.2
140/2030.5 18.5/4.8
160/2320.6 10.5/2.7
168/2436.6 5/1.3
Travel gear/swivel unit Model 803
Travel speeds 1.82 kph (1.13 mph)
Hill climbing ability
(no longer than 3 minutes)
30°/58 %
Track width 180 mm (7.09'')
No. of track rollers on either side 2
Ground clearance 132 mm (5.2'')
Ground pressure 0.24 kg/cm² (3.4 psi)
Upper carriage swivel speed 8 rpm
Stabilizer blade Model 803
Width (folded in/out) 700/860 mm (27.55"/33.85")
Height 198 mm (7.8'')
Max. lift over/under subgrade 197/174 mm (7.76"/6.85")
Location Thread Gap dimension
Stabilizer blade 3/8" 0.3 mm (0.012'')
