Technical data
2.15 Lift capacity table 803 RD
Refer to the Operator’s Manual of the machine for specific data.
2.16 Kinematics
E Pin diameter 25 mm (0.98'')
F Stick width 100 mm (3.9'')
L
Pin distance from
bucket mount
165 mm (6.5'')
Bucket
Stick
