SHB 803 en – Edition 2.4 * 803s510.fm 5-7
Hydraulic system
Legend
Main control lines
Pump/reservoir lines
Connection Legend
B1 Rotation to the left
A1 Rotation to the right
B2 Stick cylinder rod side
B1 Stick cylinder base side
B3 Left-hand traveling drive reverse
A3 Left-hand traveling drive forward
B4 Stabilizer blade/telescopic undercarriage rod side
A4 Stabilizer blade/telescopic undercarriage base side
A5 Auxiliary hydraulics
B5 Closed
A6 Right-hand traveling drive forward
B6 Right-hand traveling drive reverse
A7 Swiveling cylinder rod side
B7 Swiveling cylinder base side
A8 Bucket cylinder base side
B8 Bucket cylinder rod side
A9 Boom cylinder rod side
B9 Boom cylinder base side
Connection Legend
P1 Pump 1 connection
P2 Pump 2 connection
T1 Reservoir line via non-return valve and filter in reservoir
