SHB 803 en – Edition 2.4 * 803s611.fm 6-15
6.17 Traveling signal wiring harness (option)
Strand From To mm² Color
1 X1.1/1 1 blu 2 X1/1 S78.1 1 blk 3 X1/1 S78.2 1 blk 4 S78.1 X2/1 1 blu 5 S78.2 X2/1 1 blu 6 S78.1 X3 1 red 7 S78.2 X3 1 red 8 X2/2 X1/2 1 blk 9 X1.1/2 1 blk
