WAGO Compact Controller 100 User Manual

WAGO I/O System Compact e!RUNTIME Runtime Environment 109
751-9301 Compact Controller 100
Manual
Version 1.1.0, valid from FW Version 03.08.07(20)
9.4 Process Image
9.4.1 Analog Inputs
The analog inputs AI1 and AI2 are represented per channel via the WORD data
type (16 bit).
Table 49: Process Image – Analog Inputs
Chan-
nel
Pin
Data
Type
Mea-
sured
Value
Value Range
Hex.
Dec.
Bin.
AI1 X14.1
WORD
0 …
10 V
0x0000 …
0x7FF8
0 … 32760
0000.0000.
0000.0000 …
.0111.1111
1111.1000
AI2 X14.3 > 10 V 0x7FFB 32763
0111.1111.
1111.1011
9.4.2 Analog outputs
The analog outputs AO1 and AO2 are represented per channel via the WORD
data type (16 bit).
Table 50: Process Image – Analog Outputs
Chan-
nel
Pin
Data
Type
Mea-
sured
Value
Value Range
Hex.
Dec.
Bin.
AO1 X6.1
WORD
0
…
10 V
0x0000
…
0x7FFF
0
… 32767
0000.0000.
0000.0000
…
0111.1111.
1111.1111
AO2 X6.3
