32 Properties WAGO I/O System Compact
751-9301 Compact Controller 100
Manual
Version 1.1.0, valid from FW Version 03.08.07(20)
4.1.3.7 Analog Temperature Sensors
The connections are used to connect actuators and sensors.
picoMAX® plugs with Push-in CAGE CLAMP® Connections are used.
Analog temperature sensors such as Pt1000 or Ni1000 can be connected to the
controller.
The resistance values are converted into temperature values. A microprocessor
linearizes the measured resistance values and converts them into a numeric
value proportional to the temperature of the selected resistance sensor.
The controller has 2 input channels, providing a direct connection to 2-wire
resistance sensors.
Table 12: Analog Temperature Sensors – “X13”
Contact
Signal
Description
1
PT1+
Analog input Pt1000/Ni1000
2
PT1–
3
PT2+
4
PT2–
