WAGO Compact Controller 100 User Manual

WAGO I/O System Compact Function Description 67
751-9301 Compact Controller 100
Manual
Version 1.1.0, valid from FW Version 03.08.07(20)
Table 40: Loading a Boot Project
Boot Project
Stored in
Internal Flash
Memory
Memory Card
with Boot
Project
Inserted
“Home
Directory on
Memory Card
Enabled”
Checked
Boot Project is
Loaded ...
No
No
No
No, no boot project exists
Yes
No, no boot project exists
Yes
No
No, no boot project exists in the
internal flash memory
Yes
Yes, from memory card
Yes
no
No
Yes, from internal flash memory
(Yes) invalid
No, invalid combination, since
no boot project is allowed to
exist in the internal flash
memory for this setting
Yes
No
Yes, from internal flash memory
(Yes) invalid
No, invalid combination, since
no boot project is allowed to
exist in the internal flash
memory for this setting
