Proper operating procedures 4-3
Proper operating procedures
Removing the front left panel cover
To remove the front left panel cover:
1. Holding on to the top of the cover, gently pull the bottom away from the
unit.
2. Gently remove the top of the cover and store it nearby.
The figure below illustrates the detector with the front left panel cover
removed.
Detector with front left front panel cover removed
Caution:
• There are no user-serviceable parts inside the detector. Do not
remove the top cover.
• To maintain optimum performance, replace the front left panel
cover before resuming normal operation of the detector.
TP02806
