Waters 2489 - Optical Specifications

B-4 Detector Specifications
Fuse ratings Two fuses:
100 to 240-Vac, 50 to 60-Hz
F 3.15-A 250-V fast blo, 5 × 20 mm (IEC)
Attenuated analog
output channel:
2 VFS
Attenuation range: 0.0001 to 4.000 AU
2-V output range: –0.1 to +2.1 V
Two event outputs Type: Contact closure
Voltage: +30 V
Current: 1 A
Four event inputs Input voltage: +30 V maximum
100-ms minimum period
Dimensions
Height 20.8 cm (8.2 inches)
Length 50.3 cm (19.8 inches)
Width 28.4 cm (11.2 inches)
Weight 9.3 kg (~20.5 pounds)
Optical specifications
Optical specifications
Condition Specification
Monochromator type Fastie-Ebert
Grating Plane holographic
1800 grooves/mm
Optical bandwidth 5 nm
Lamp power 30 W
Operational specifications
Condition Specification
