Waters 2489 - Assembling the Fittings

2-8 Installing the Detector
Detector fluid line connections
Assembling the fittings
To assemble each fitting
1. Slide the compression screw over the tubing end, followed by the ferrule.
2. Mount the ferrule with its taper end facing the end of the tubing.
TP02810
Inlet
Outlet
(labeled)
