Preparing for installation 2-3
Detector dimensions
Caution: Do not access the instrument through the top cover. Access
the instrument through the front left panel where the lamp housing,
flow cell assembly, and cuvette holder are located.
TP02804
28.4 cm (11.2 inches)
50.3 cm (19.8 inches)
20.8 cm (8.2 inches)
