Chapter 4
4-6 Printer-Applicator User’s Manual
Figure 4-5: Upstream Edge of Tamp Pad Close to Printer Peeler Bar
Figure 4-6: Tamp Pad Label Alignment
Manifold Knobs
(4)
Tamp Assembly
Lever
Handles
