Applicator Setup
Weber Packaging Solutions, Inc. 4-17
To adjust the low label sensitivity:
1. Push the unwind roll dancer arm toward the printer.
2. Rotate the unwind roll until the opening in the inner unwind disk is right in front of the
low label sensor.
3. Remove the back cover from the low label sensor (Banner sensor only).
4. Set the output select switch to the Dark Operate (DO) position (Banner sensor only).
Banner sensor: Turn the adjustment screw until a red spot is focused sharply
on the label roll.
Optex sensor: Turn the adjustment dial until the yellow LED stays on.
5. Rotate the unwind disk until the red spot is directed away from the opening and onto the
disk itself. The red LED (Banner sensor) or yellow LED (Optex sensor) should stay
[ON].
Note: Adjust the sensitivity (if necessary) until the LED remains on when the
unwind disk or the label roll is in front of the sensor.
6. Rotate the unwind disk until the red spot is directed through the opening onto the label
roll.
7. Take the outer unwind disk off and remove the label roll from the unwind mandrel. The
LED should then go OFF.
