CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
126
Range
[Factory Setting]
Parameter Unit Description / Notes
ThisparameterenablesthexedslowspeedwithJog.
 Slow speed with Jog forward direction is about 1/7 of the nominal
speed.
 Slow speed with Jog reverse direction is about 1/11 of the nominal
speed.
P510
(1)
Jog
0 to 1
[ 0=Inactive ]
-
Table 6.40 - Jog selection
Table 6.41 - Jog and motor direction of rotation
 This parameter sets the slow speed torque level with Jog.
ATTENTION!
1. Be careful with this torque level. Set it according to the
application so that the Soft-Starter SSW-06 and the motor
can withstand the settings.
2. The motor can be enabled during a short period of time
only, with Jog. Connect a push-button to a digital input to
enable the Jog.
3. The P102 parameter is the time limit protection of the Jog.
If this time is exceeded, fault E62 will appear.
4. The parameters: P001, P002, P003, P008, P009, P010
and P011 are set to zero during the Jog Function.
5. The current protections do not work with the Jog current
because the current transformers saturate with the low
Jog frequency.
6. The Soft-Starter SSW-06 does not protect the motor during
a Jog without the use of a PTC sensor on the motor.
7. To correctly measure the currents during the Jog, it is
necessarytousehalle󰀨ecttransformers.
P511
JogLevel
10 to 100
[ 30 ]
1%
P510 Action
0 Inactive
1 Active
P510 P231 Action
0 Inactive) - without Jog
1 (Active) 0 (Inactive) allows the slow speed with Jog only in forward
direction.
1 (Active) 1 (By Contactor) allows the slow speed with Jog in the same
direction of the power supply and the auxiliary
contactors connected at the input power
supply, changing the motor direction of
rotation.
1 (Active) 2 (JOG Only) allows the slow speed with Jog in both forward
and reverse directions without contactors.
