DESCRIPTION OF THE ACTUATION
When the DI6 digital input is programmed to
the motor PTC input and the detector acts.
It acts as the levels:
P091 ≥ P672 = E33
P091 ≥ P673 = A33
It acts as the levels:
P092 ≥ P676 = E34
P092 ≥ P677 = A34
It acts as the levels:
P093 ≥ P680 = E35
P093 ≥ P681 = A35
It acts as the levels:
P094 ≥ P684 = E36
P094 ≥ P685 = A36
It acts as the levels:
P095 ≥ P688 = E37
P095 ≥ P689 = A37
The PT106 optional board was not detected
with P670 active.
When the conversion of the input current is
out of allowed range: 2,5V ±3%.
It detects the opening of the circuit of the
temperature channels, through the break of
some of the three wire of each sensor.
POSSIBLECAUSES
Excessive load on the shaft.
Loadcycletoohigh(largenumberofstartsand
stops per minute).
Ambient temperature too high.
Loosecontactorshort-circuit(resistance<100)in
the wiring from motor thermistor to X1 terminal of
the CCS6 board.
P268 is set to 7 without a thermistor installed at the
motor.
Stalled motor, locked rotor.
Motor overtemperature.
Motor overload.
Loadcycletoohigh(largenumberofstartsand
stops per hour).
Motor not develops the necessary torque for the
load.
Errorsandalarmslevelsadjustedarelowerthat
supported by the motor (motor class isolation).
PT106 optional board with problems.
If PT106 optional board will not being used, to
program P670=0.
Looseelectriccontactinthecurrenttransformer
cables or control board connection cables.
A thyristor or contactor in short-circuit.
Problems in the control board.
Motor temperature sensor with wire broken or
opened.
Temperaturechanneladjustedforerrororalarm
without sensor.
Connectors of the PT106 board not connected.
Comment:
Programming of the broken wire actuation as error
or alarm is in the P691.
RESET
Power-on
Manual Reset
Auto-reset
DIx
Power-on
Manual Reset
Auto-reset
DIx
Power-on
Manual Reset
Auto-reset
DIx
Power-on
Manual Reset
DIx
Power-on
Manual Reset
Auto-reset
DIx
Table 8.1 (Cont.) - Detailed fault description
FAULT
E32 or A32
Motor overtemperature
(DI6 = PTC)
E33 or A33
Motor Overtemperature
Ch1
E34 or A34
Motor Overtemperature
Ch2
E35 or A35
Motor Overtemperature
Ch3
E36 or A36
Motor Overtemperature
Ch4
E37 or A37
Motor Overtemperature
Ch5
E39
Without PT106 optional
board
E41
Self-Diagnosis fault
during power-on
E43 or A43
Ch1 Motor Temperature
Broken Cable
E44 or A44
Ch2 Motor Temperature
Broken Cable
E45 or A45
Ch3 Motor Temperature
Broken Cable
E46 or A46
Ch4 Motor Temperature
Broken Cable
E47 or A47
Ch5 Motor Temperature
Broken Cable
