CHAPTER 8 - DIAGNOSTICS AND TROUBLESHOOTING
168
NOTES!
Fault Actuation Results:
E24:
-IndicatesthecodeintheLEDdisplayandthefaultdescriptioninthe
LCDdisplay(seetable4.2);
- Motor can not be started;
-Switcheso󰀨therelaythathasbeenprogrammedto"NoError";
- Switches on the relay that has been programmed to "With Error".
E28, E29 and E30:
-IndicatesthecodeintheLEDdisplay;
-IndicatesthecodeandthefaultdescriptionintheLCDdisplay;
-TheactuationresultcanbeconguredatP313.
E31:
- Soft-Starter proceeds operation normally;
- No Keypad commands are accepted;
-IndicatescodeintheLEDdisplay;
-IndicatesthecodeandthefaultdescriptionintheLCDdisplay.
E41:
- Soft-Starter operation is not allowed (motor can not be started);
-IndicatescodeintheLEDdisplay;
-IndicatesthecodeandthefaultdescriptionintheLCDdisplay.
E70:
- It will not be saved in the last six faults memory when the power
supplyisswitchedo󰀨(linedisconnection)withstoppedmotor.
NOTES!
When E04 message is displayed (Soft-Starter overtemperature), wait
a few minutes for it to cool down before it can be reset.
When E05 message is displayed (motor overload) or E32 (motor over-
temperature), wait a few minutes for the motor to cool down slightly
before the Soft-Starter can be reset.
FAULT
E81 or A81
Overpower
E85
WithoutSoftPLC
E86 to E89
SoftPLCusererrors
A90 to A93
SoftPLCuseralarms
DESCRIPTION OF THE ACTUATION
When the value of the active power is higher
than the programmed value, longer than the
programmed time. Referenced to the nominal
motor power.
Itveriestheexistenceofausersoftware.
When forced by the user software.
When forced by the user software.
POSSIBLECAUSES
The percentage value programmed as maximum
acceptable Overpower limit (P662) is below the
necessary for the motor and the application. Tran-
sitory excess of load at the motor. Locked motor,
blocked rotor.
P950=1withoutSoftPLC.
DenedbytheSoftPLCuser.
DenedbytheSoftPLCuser.
RESET
Power-on
Manual Reset
Auto-reset DIx
Power-on
Manual Reset
DIx
Power-on
Manual Reset
DIx
Power-on
Manual Reset
DIx
Table 8.1 (Cont.) - Detailed fault description
