CHAPTER 8 - DIAGNOSTICS AND TROUBLESHOOTING
173
Table 8.5 - Spare parts list line 575-690Vac
* a) The 110Vac fan is used in the SSW06xxxxT5769ESH1Z
b) The 220Vac fan is used in the SSW06xxxxT5769ESH2Z
Name Item Number Specication
Models (Amperes) 575-690Vac
45 60 85 130 170 205 255 312 365 412 480 604 670 820 950 1100 1400
Units per Soft-Starter
Thyristor
Module
10954635 Thyristor Module 72A 1800V 3
10954636 Thyristor Module 92A 1800V 3
10954749 Thyristor Module 142A 1800V 3
10954710 Thyristor Module 250A 1800V 3 3
Disc Thyristor
10954717 Disc Thyristor 508A 1800V 6 6 6
10954963 Disc Thyristor 550A 1800V 6
10955053 Disc Thyristor 750A 1800V 6
10954961 Disc Thyristor 900A 1800V 6
10954962 Disc Thyristor 1200A 1800V 6 6 6
11034525 Disc Thyristor 1500A 1800V 6
11034526 Disc Thyristor 1800A 1800V 6
11034527 Disc Thyistor 3000A 1800V 6
Fan
10192264 Fan 120x120mm 110V/220Vac 2 2 2 2 2 2 2 3 3
10192261 Fan 225x225mm 220Vac* 2
10192262 Fan 225x225mm 110Vac* 2
10192259 Fan 280x280mm 220Vac* 2 2
Fuse-Control 10328719 Glass Fuse 2A 250V 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Keypad (HMI) 10052068 Human Machine Interface 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
CCS6 10413450 Control Board 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
CPS66.00 10051643 Source and Power Board 1 1 1 1 1 1 1
CPS66.01 10051661 Source and Power Board 1 1 1
CPS66.02 10725940 Source and Power Board 1 1
CPS65 10092578 Source and Power Board 1 1 1 1 1
RCS60 10051644 RC Snubber Board 1 1 1 1 1
RCS61 10051654 RC Snubber Board 1 1 1 1 1 1 1 1 1
Current
Transformer
10726214 CT 225/0,426A 1VA 2,5% 3
10726217 CT 300/0,426A 1,4VA 2,5% 3
10050181 CT 425/1,24A 2,8VA 2,5% 3
10050182 CT 650/1,24A 4,3VA 2,5% 3
10050183 CT 850/1,24A 4,7VA 2,5% 3
10050184 CT 1025/1,24A 6,8VA 2,5% 3
10050185 CT 1275/1,24A 7,5VA 2,5% 3
10050186 CT 1560/1,24A 9,1VA 2,5% 3
10050187 CT 1825/1,24A 10VA 2,5% 3
10050194 CT 2060/2A 8VA 2,5% 3
10050195 CT 2400/2A 10VA 2,5% 3
10050196 CT 3020/2A 12VA 2,5% 3
10050197 CT 3350/2A 13VA 2,5% 3
10050198 CT 4100/2A 12VA 2,5% 3
11101957 CT 4750/2A 27VA 2,5% 3
11102008 CT 5500/2A 36VA 2,5% 3
11101830 CT 7000/2A 46VA 2,5% 3
By-pass Relay
10190576 LatchingRelay100A48Vdc 3 3 3
10190577 LatchingRelay200A48Vdc 2 2 3 3 3 3
By-pass
Contactor
10046674 Contactor CWM105DP-SB955 3 3 3 3 3
RC Snubber
10190163 Wire Resistor 25R 50W 10% 3 3 3
10190364 Polip. Capacitor 0.47µF 850V 3 3 3
