WEG SSW-06 User Manual

CHAPTER 2 - GENERAL INFORMATION
29
NOTE! Theoptioneld(SorO)denesiftheSoft-StarterSSW-06isastandardversionorifitisequippedwithanyoptionaldevices.Ifthestandardversion is required, the code ends here. The model number always has the letter Z at the end. For example: SSW060085T2257ESZ = Standard Soft-Starter SSW-06 with current of 85A and 220V to 575V with manual in English. Ifthereareaccessories,thespacesmustbelledoutinthecorrectsequenceuntilthecodeendswiththeletterZ. Thestandardproductisdenedasdescribedhere:  Degree of protection: IP20 from 10A to 30A.  Degree of protection: IP00 from 45A to 1400A.  Human-MachineInterface:HMI-SSW06(withLCDandLEDdisplays). Note: The communication kits are optional, see chapter 9. (1) Model 10A, 16A, 23A and 30A not available in the line 690V.
Nominal output current: 0010=10A
(1)
0016=16A
(1)
0023=23A
(1)
0030=30A
(1)
0045=45A 0060=60A 0085=85
A
0130=130A 0170=170A 0205=205A 0255=255A 0312=312A 0365=365A 0412=412A 0480=480A 0604=604A 0670=670A 0820=820A 0950=950A 1100=1100A 1400=1400A
Thee-phase power supply
Power supply voltage: 2257 = (220 to 575)V 5769 = (575 to 690)V
Manual language: P=portuguese E=english S=spanish G=german
Human- Machine Interface (Keypad): Blank = stan- dard SI= without keypad
Special sof- tware: Blank = stan- dard S1=special software
Special hardware: Blank = standard H1 = 115V ventilation (model 950A) H2 = 230V ventilation (models 950A, 1100A and 1400A)
Soft-Starter SSW-06 WEG Series
End of code
Options: S=standard O=with options
HOW TO SPECIFY THE SSW-06 MODEL:
SSW-06 0085 T 2257 E S _ _ _ _ _ _ Z
