CHAPTER 3 - INSTALLATION AND CONNECTION
40
d) Models: 255A to 604A (220 - 575V) or 205A to 604A (575-690V)
* Dimensions in mm (in)
e) Models: 670A and 820A
* Dimensions in mm (in)
M10 (12x)
IN PUT TERM IN AL
POW ER
OUTPUT TERM IN AL
POW ER
179.5
(7.07)
(7.07)
179.5
41
(1.61)
41
35
63.559.8
(1.38)
(1.61)(2.35) (2.50)
63.5
41
(1.61)(2.50)
30
80
(3.15)
(1.18)
25
(0.98)
(0.98)
25
M12 (12x)
INPUT TERMINAL
POWER
OUTPUT TERMINAL
POWER
214.3
(8.44)
214.3
(8.44)
95
(3.74)
29.7
(1.17)
(2.36)
60
85
(3.35)
60
(3.35)
85
(2.36)
(2.36)
60
120
(4.72)
23.9
(0.94)
25
(0.98)
25
(0.98)
Figure 3.8 d) e) - Power terminals
