CHAPTER 3 - INSTALLATION AND CONNECTION
49
Model
Nominal
Rating
Short Circuit
Rating
≤480V
Circuit Breaker
(DIVQ)
Short Circuit
Rating
≤600V
Circuit Breaker
(DIVQ)
Minimum Enclosure
Dimensions
(WxHxL)(mm)
SSW-06.0010 10 A 65 kA
WEG ACW125W-FTU15-3 or
UBW225H-FTU40-3AorHFD3040L
18 kA
UBW225H-FTU40-3 A or
HFD3040L
800 600 300
SSW-06.0016 16 A 65 kA
WEG ACW125W-FTU15-3 or
UBW225H-FTU40-3AorHFD3040L
18 kA
UBW225H-FTU40-3 A or
HFD3040L
800 600 300
SSW-06.0023 23 A 65 kA
WEG ACW125W-FTU15-3 or
UBW225H-FTU40-3AorHFD3040L
18 kA
UBW225H-FTU40-3 A or
HFD3040L
800 600 300
SSW-06.0030 30 A 65 kA
WEG ACW125W-FTU15-3 or
UBW225H-FTU40-3AorHFD3040L
18 kA
UBW225H-FTU40-3 A or
HFD3040L
800 600 300
SSW-06.0045 45 A 65 kA
WEG ACW125W-FTU125-3 or
UBW225H-FTU150-3AorHFD3150L
18 kA
UBW225H-FTU150-3 A or
HFD3150L
1000 600 400
SSW-06.0060 60 A 65 kA
WEG ACW125W-FTU125-3 or
UBW225H-FTU150-3AorHFD3150L
18 kA
UBW225H-FTU150-3 A or
HFD3150L
1000 600 400
SSW-06.0085 85 A 65 kA
WEG ACW125W-FTU125-3 or
UBW225H-FTU150-3AorHFD3150L
18 kA
UBW225H-FTU150- 3A or
HFD3150L
1000 600 400
SSW-06.0130 130 A 65 kA
WEG ACW250W-FTU160-3 or
UBW225H-FTU225-3AorHFD3225L
18 kA
UBW225H-FTU225-3 A or
HFD3225L
1000 600 400
SSW-06.0170 170 A 65 kA
WEG ACW250W-FTU200-3 or
UBW250H-FTU250-3A or HJD3250
30 kA
UBW250L-FTU250-3Aor
JDC3250
1000 600 400
SSW-06.0205 205 A 65 kA
WEG ACW250W-FTU200-3 or
UBW250H-FTU250-3A or HJD3250
30 kA
UBW250L-FTU250-3Aor
JDC3250
1000 600 400
SSW-06.0255 255 A 65 kA
WEG ACW400W-FTU300-3 or
UBW400H-FTU400-3A or HKD3400
30 kA
UBW400H-FTU400-3 A or
HKD3400
1200 900 400
SSW-06.0312 312 A 65 kA
WEG ACW400W-FTU300-3 or
UBW400H-FTU400-3A or HKD3400
30 kA
UBW400H-FTU400-3 A or
HKD3400
1200 900 400
SSW-06.0365 365 A 65 kA
WEG ACW800W-FTU500-3 or
UBW600H-FTU600-3AorHLD3600
42 kA
UBW600L-FTU600-3Aor
LDC3600
1200 900 400
SSW-06.0412 412 A 65 kA
WEG ACW800W-FTU800-3 or
UBW600H-FTU600-3AorHLD3600
42 kA
UBW600L-FTU600-3Aor
LDC3600
1200 900 400
SSW-06.0480 480 A 65 kA
WEG ACW800W-FTU800-3 or
UBW600H-FTU600-3AorHLD3600
42 kA
UBW600L-FTU600-3Aor
LDC3600
1200 900 400
SSW-06.0604 604 A 65 kA
WEG ACW800W-FTU800-3 or
UBW800H-FTU800-3AorHMDL3800
- - 1200 900 400
SSW-06.0670 670 A 65 kA
WEG ACW800W-FTU800-3 or
ABB T7H 1200 or NGC312033E or
UBW1200L-ELS1200-3A
- - 1220 1220 405
SSW-06.0820 820 A 65 kA
ABB T7H 1200 or
NGC312033E or
UBW1200L-ELS1200-3A
- - 1220 1220 405
SSW-06.0950 950 A 65 kA
UBW1200H-ELS1200-3Aor
NGH312033EC
- - 2000 800 600
SSW-06.1100 1100 A -
-
- - 2200 1000 600
SSW-06.1400 1400 A -
-
- - 2200 1000 600
Table 3.9 - Short circuit capacity standard connection - UL High Fault
