Overview of the control panels
22 Operating Manual
Switching between the different organ models
As soon as you have pressed the Drawbars Live control panel button, the mapping appears, on which you
can select the desired organ sounds.
Here you have the following options:
In the factory setting, the Factory display button is selected. A few main sounds of all existing organ models
are displayed. With the actual software, these are the sounds of the OX7, the VB3 and the Farfisa Compact.
Your instrument remembers which organ sounds you use most often. Up to 15 sounds are saved under
Favorites. If you are working with the instrument for the first time, this display will of course be empty.
You can also create your own mapping and store the drawbar sounds you use most of all organ types under a
Own (mapping).
Under USER you will find the drawbar sounds you have saved yourself.
Via the larger display symbols OX7, VB3 or
Farfisa you have access to all the factory
sounds of the respective organ.
In our example, you can see that there are
more than 15 sounds by the display “2/5”.
There are a total of five pages with sounds
from the "OX7" area and the illustration
shows page 2 of 5.
With a swipe from left to right or right to left, you can switch between the individual pages. If you don't want
to select the mappings by swiping, you can also use the arrows at the bottom left and right.
